Portainer CE by default doesnt support Entra ID (formerly Azure AD) for SSO.
Mostly because it’s for non-commercial use, but I actually have a private Microsoft 365 tenant for myself, so I wanted to use Entra ID Authentication for that.
With this guide, I will tell you how you can use custom oAuth to configure Entra ID sign in, since it wasn’t a breeze to find out myself.
Why Use Entra ID with Portainer CE?
- Single Sign-On (SSO): Use Entra ID credentials to log in to Portainer.
- Enhanced Security: Enforce policies such as multi-factor authentication (MFA) via Entra ID.
- Simplified User Management: Centralize access control through your existing Entra ID setup.
Prerequisites
- A running instance of Portainer CE (version 2.9 or later).
- An Entra ID tenant (part of a Microsoft 365 or Azure subscription).
- Administrative privileges on both Entra ID and Portainer CE.
Step 1: Register an App in Entra ID
- Log in to Entra ID Portal:
- Visit the Entra ID Portal.
- Create a New App Registration:
- Go to Azure Active Directory > App Registrations > + New Registration.
- Provide a name for the app (e.g.,
Portainer OAuth
). - Set Supported Account Types:
- Single Tenant (if only your organization will use Portainer).
- Add a Redirect URI:
- Type: Web
- URI:
https://<your-portainer-url>
- Replace
<your-portainer-url>
with your Portainer CE domain or IP address. (HTTPS is required for SSO)
- Click Register.
- Save the Key Details:
- After registration, copy:
- Application (client) ID
- Directory (tenant) ID
Step 2: Configure Permissions in Entra ID
- Add API Permissions:
- Go to API Permissions > + Add a permission.
- Select Microsoft Graph > Delegated Permissions.
- Add:
openid
profile
email
- Click Grant admin consent to apply permissions for all users.
- Create a Client Secret:
- Go to Certificates & Secrets > + New Client Secret.
- Add a description (e.g.,
Portainer OAuth
). - Set an expiration period (e.g., 12 months).
- Save the Client Secret value. You’ll need it for Portainer.
Step 3: Configure Custom OAuth in Portainer CE
- Log in to Portainer:
Access your Portainer CE instance as an administrator. - Navigate to Authentication Settings:
- Go to Settings > Authentication.
- Select the Custom OAuth provider.
- Enter the Entra ID OAuth Details:
Use the following settings based on your configuration:
- Client ID:
<Your Application (client) ID>
- Client Secret:
<Your Client Secret>
- Authorization URL:
https://login.microsoftonline.com/<Your-Tenant-ID>/oauth2/v2.0/authorize
- Access Token URL:
https://login.microsoftonline.com/<Your-Tenant-ID>/oauth2/v2.0/token
- Resource URL:
https://graph.microsoft.com/v1.0/me
- Redirect URL:
https://<your-portainer-url>
- Logout URL:
https://login.microsoftonline.com/<Your-Tenant-ID>/oauth2/v2.0/logout
- User Identifier:
userPrincipalName
- Scopes:
openid profile
- Auth Styles: in params
Step 4: Test the Integration
- Log out of Portainer and access the login page.
- You should see the OAuth login option.
- Authenticate using your Entra ID credentials.
- If successful, you will be redirected to Portainer’s dashboard, don’t forget to give the account permissions, because you can’t add it automatically to a team with the community edition of Portainer!
Common Issues and Troubleshooting
- Unauthorized Error:
- Ensure that In Params is the Auth Style
- Redirect URI Mismatch:
- Ensure the Redirect URI in Portainer matches exactly with what is configured in Entra ID, no oauth/callback as stated by some guides.
- Missing Claims:
- Add optional claims in Entra ID:
- Go to Token Configuration > + Add optional claim.
- Add the following claims for the ID token:
email
name
upn
(User Principal Name).
- Token Validation Errors:
- Ensure
openid
,profile
, andemail
scopes are properly configured and granted admin consent.
Conclusion
Integrating Portainer CE with Entra ID provides a secure and centralized authentication solution for your containerized environments. By leveraging OAuth, you can streamline user access, enforce MFA, and manage access control directly from Entra ID.
